SWL2.5, SWL5 SWL10, SWL15 SWL20, SWL25, SWL35, SWL50, SWL100, etc
HUAKE
HUAKE heavy-duty worm screw jack (SWL series) is a foundational industrial lifting component, engineered for reliable height adjustment, lifting, and propulsion operations across diverse heavy-load manufacturing scenarios. As a versatile industrial lifting screw jack, it supports both single-unit operation and synchronized multi-unit systems, delivering precise height control with strict accuracy standards. This electric worm screw lift can be directly driven by electric motors or manually operated, with diverse structural and assembly configurations to adapt to complex working conditions. Widely adopted in machinery, metallurgy, construction, and water conservancy equipment industries, it fulfills lifting, lowering, flipping, and multi-position height adjustment demands for industrial business clients.
With an integrated compact structure, this mechanical lifting screw jack features small footprint, light weight, and low noise operation, making it easy to install in space-constrained industrial setups without sacrificing load capacity.
Built with wear-resistant core components and rigid structural design, it delivers stable performance under continuous heavy-load operation, with minimal maintenance requirements and extended service life for long-term industrial production.
It supports both electric drive (compatible with various standard and servo motors) and manual operation, ensuring uninterrupted operation even during power outages. It can be freely combined into synchronized systems for large-scale lifting tasks.
Multiple assembly types and lifting stroke options are available, with full customization support to meet unique height adjustment and load-bearing requirements of different industrial processes.
Model Series | Rated Load Capacity | Input Power Range | Standard Stroke | Max Custom Stroke | Drive Type | Lifting Accuracy |
|---|---|---|---|---|---|---|
SWL2.5-SWL10 | 2.5T × 10T | 0.37kW × 1.5kW | 100mm × 500mm | Up to 3000mm | Electric / Manual | ≤0.1mm/mm |
SWL15-SWL35 | 15T × 35T | 1.5kW × 3kW | 200mm × 800mm | Up to 5000mm | Electric / Manual | ≤0.1mm/mm |
SWL50-SWL100 | 50T × 100T | 3kW × 7.5kW | 300mm × 1000mm | Up to 6000mm | Electric / Manual | ≤0.1mm/mm |
*Brand: HUAKE | Custom parameters available on request* | |||||
This industrial height adjustment screw jack is widely deployed across core industrial sectors: metallurgical equipment height adjustment and furnace door lifting, water conservancy project gate control systems, construction machinery lifting platforms, mechanical manufacturing fixture and tooling position adjustment, stage equipment lifting systems, new energy equipment assembly lines, and warehousing logistics lifting and positioning systems.
The core worm gear is made of high-strength tin bronze for exceptional wear and impact resistance, while the worm shaft adopts alloy structural steel with quenching and tempering treatment for high rigidity and fatigue resistance. The lifting screw uses high-quality 45# steel or alloy steel with precision rolling and quenching treatment, ensuring stable transmission and long-term load-bearing capacity. All components are processed via CNC machining centers, with strict precision testing and heat treatment processes to guarantee dimensional accuracy and transmission stability.
We offer comprehensive customization services for industrial manufacturing enterprises: custom lifting stroke up to 6000mm, special flange mounting dimensions, anti-corrosion and high-temperature protective coatings, motor interface customization for servo/stepper/explosion-proof motors, multi-unit synchronized lifting system design, and non-standard structural modification. We also provide full OEM/ODM solutions, including brand labeling, custom packaging, and technical drawing co-development, to align with your brand and production requirements.
Our standard SWL series heavy-duty worm screw jack supports rated load capacity from 2.5T to 100T, with custom larger load specifications available for special heavy-load industrial scenarios.
Yes. It can be equipped with linkage shafts, encoders, and industrial control systems to achieve high-precision synchronized lifting of multiple units, with adjustable synchronization accuracy to meet your process requirements.
All models support optional manual operation configuration, ensuring reliable lifting and adjustment operations even during unexpected power outages, to avoid production interruptions.
As a trusted supplier for industrial enterprises, we provide one-to-one professional technical selection support, free 2D/3D drawing design, sample testing services, and fast bulk delivery. Contact us today to get a tailored industrial height adjustment screw jack solution that perfectly matches your specific working conditions and production needs.
